M-One 6 APC
| Table | ||
| Area of Table | mm | 600 x 400 |
| Working Area | mm | 600 x 400 |
| T-Slot | mm | 14 x 3 x 100 |
| Work Table Max Weight | kgs | 200 x 2 |
| Travel | ||
| X-Axis Travel | mm | 600 |
| Y-Axis Travel | mm | 400 |
| Z-Axis Travel | mm | 550 |
| X/Y/Z-Guideway type | Linear Guideway | |
| Spindle | ||
| Spindle Taper | BT40 | |
| Spindle R.P.M. | rpm | 10000 |
| 3-Axis Rapid Traverse | m/min | 36/36/36 |
M-One 8 APC
| Table | ||
| Area of Table | mm | 850 x 500 |
| Working Area | mm | 850 x 500 |
| T-Slot | mm | 18 x 5 x 100 |
| Work Table Max Weight | kgs | 300 x 2 |
| Travel | ||
| X-Axis Travel | mm | 850 |
| Y-Axis Travel | mm | 500 |
| Z-Axis Travel | mm | 550 |
| X/Y/Z-Guideway type | Linear Guideway | |
| Spindle | ||
| Spindle Taper | BT40 | |
| Spindle R.P.M. | rpm | 10000 |
| 3-Axis Rapid Traverse | m/min | 36/36/36 |
M-One 10 APC
| Table | ||
| Area of Table | mm | 1000 x 500 |
| Working Area | mm | 1000 x 500 |
| T-Slot | mm | 18 x 5 x 100 |
| Work Table Max Weight | kgs | 300 x 2 |
| Travel | ||
| X-Axis Travel | mm | 1000 |
| Y-Axis Travel | mm | 500 |
| Z-Axis Travel | mm | 600 |
| X/Y/Z-Guideway type | Linear Guideway | |
| Spindle | ||
| Spindle Taper | BT40 | |
| Spindle R.P.M. | rpm | 10000 |
| 3-Axis Rapid Traverse | m/min | 36/36/36 |
