ML-46C
Capacity
Max. Turning Diameter (disc) mm -
Max. Turning Diameter (axis) mm Φ42
Max. Turning Length mm 200
Max. Dia of Bar Bore mm Φ45
Travel
X/Z Travel mm 790/250
Swing Over Bed mm Φ400
Swing Over Slide mm Φ140
Spindle
Spindle Head Type (ASA)   A2-5
Spindle RPM rpm 6000
Chuck Type   Collet chuck
Turret
Number of Tools Units Gang type tool plate



ML-46J
Capacity
Max. Turning Diameter (disc) mm Φ380
Max. Turning Diameter (axis) mm Φ130
Max. Turning Length mm 200
Max. Dia of Bar Bore mm Φ45
Travel
X/Z Travel mm 790/250
Swing Over Bed mm Φ400
Swing Over Slide mm Φ140
Spindle
Spindle Head Type (ASA)   A2-5
Spindle RPM rpm 6000
Chuck Type   6" Chuck
Turret
Number of Tools Units Gang type tool plate



ML-280
Capacity
Max. Turning Diameter (disc) mm Φ400
Max. Turning Diameter (axis) mm Φ210
Max. Turning Length mm 400
Max. Dia of Bar Bore mm Φ52
Travel
X/Z Travel mm 210/400
Swing Over Bed mm Φ470
Swing Over Slide mm Φ280
Spindle
Spindle Head Type (ASA)   A2-6
Spindle RPM rpm 4000
Chuck Type   3 jaw hydraulic hollow chuck
Turret
Number of Tools Units 8



ML-280E
Capacity
Max. Turning Diameter (disc) mm Φ400
Max. Turning Diameter (axis) mm Φ210
Max. Turning Length mm 600
Max. Dia of Bar Bore mm Φ52
Travel
X/Z Travel mm 210/600
Swing Over Bed mm Φ470
Swing Over Slide mm Φ280
Spindle
Spindle Head Type (ASA)   A2-6
Spindle RPM rpm 4000
Chuck Type   3 jaw hydraulic hollow chuck
Turret
Number of Tools Units 8
