MA-745
Table
Area of Table  mm 900 x 450
Working Area  mm 700 x 450
T-Slot  mm 18 x 5 x 80
Work Table Max Weight   kgs 600
Travel
X-Axis Travel  mm 700
Y-Axis Travel  mm 450
Z-Axis Travel  mm 550
X/Y/Z-Guideway type   Linear Guideway
Spindle
Spindle Taper    BT40
Spindle R.P.M. rpm 8000
3-Axis Rapid Traverse m/min 36/36/36



MA-850
Table
Area of Table  mm 900 x 500
Working Area  mm 800 x 520
T-Slot  mm 18 x 5 x 80
Work Table Max Weight   kgs 600
Travel
X-Axis Travel  mm 800
Y-Axis Travel  mm 520
Z-Axis Travel  mm 550
X/Y/Z-Guideway type   Linear Guideway
Spindle
Spindle Taper    BT40
Spindle R.P.M. rpm 8000
3-Axis Rapid Traverse m/min 36/36/36



MA-1062
Table
Area of Table  mm 1000 x 600
Working Area  mm 1000 x 620
T-Slot  mm 18 x 5 x 100
Work Table Max Weight   kgs 800
Travel
X-Axis Travel  mm 1000
Y-Axis Travel  mm 620
Z-Axis Travel  mm 550
X/Y/Z-Guideway type   Linear Guideway
Spindle
Spindle Taper    BT40
Spindle R.P.M. rpm 8000
3-Axis Rapid Traverse m/min 36/36/36
